2001-2007 4L80E HD TRANSMISSION/4L85E 2WD WITH NEW CONVERTER

2001-2007 GMC CHEVROLET SILVERADO SIERRA SUBURBAN SAVANA EXPRESS 2500/3500 CLASSIC HD 6.0/8.1 ENGINE

2001-2007 GMC CHEVROLET SILVERADO SIERRA SUBURBAN 2500/3500 CLASSIC HD 6.0/8.1 UPRATED REMANUFACTURED ASSEMBLY FOR PERFORMANCE AND TOWING SAVANA EXPRESS

3 YEAR WARRANTY REMANUFACTURED UNIT. EXTENDED WARRANTIES NOW AVAILABLE.

CORE DEPOSIT $800. FREE LOCAL PICKUP. SHIPPING AVAILABLE

All of our transmissions are fully remanufactured and are held to the highest and strictest industry standards. What this means to you is the fact you are getting a quality product that meets or exceeds the OEM standards, not just a part that is taken apart and “patched”. We ensure that all the current updates are performed, during reassembly each unit is ran through tests to ensure correct assembly and quality.

Parts List:
TransTec Overhaul Kit – Rubber Seals, Metal Clad Seals, Sealing Rings, Paper Gaskets
Master Rebuild Kit with all clutches and steels, name brand clutches such as Borg Warner or Raybestos
Filtran Brand Transmission Filter
Bonded Pistons
Borg Warner or Raybestos Front Band
Borg Warner Carbon Lined Reverse Band
Bushing Kit
Pump Gears
New Solenoids
Updated Bronze Thrust Washers (Replaces OEM Plastic Washers)
Updated Sonnax “No Walk” Case Bushing
Updated TransGo Actuator Feed Limit Valve (Requires Reaming Tool)
Updated TransGo Zinc Coated Separator Plate

Updates to the Transmission:

• Updated TransGo Actuator Feed Limit Valve
  Also included is the TransGo Actuator Feed Limit Valve which requires a special reaming tool, that re-bores worn out aluminum 4L80E valve bodies which is typically an issue when time for a rebuild, and allows installation of this special high quality valve. This problem is the NUMBER ONE most overlooked issue by other re-builders. One indicator of this issue is the 2nd gear starts, 3rd neutral condition, no 4th gear, codes 68, 85, 86, and 87 and direct clutch breakage. The OEM actuator feed limit (AFL) valve has a large reaction area and is greatly affected by side loading, which wears the valve body bore. The EPC solenoid oscillates the torque signal and AFL oil, which increases valve action. As bore wear increases, oil pressure is reduced to the shift solenoids, which causes solenoid and ratio codes. The same AFL oil loss results in lower line pressure. If this valve is not installed, even after a rebuild transmission can have these issues and can lead to transmission failure the P1870 Code. If this valve is not installed, even after a rebuild transmission can become overheated and as a result can burn up quickly do to torque converter slippage, caused by the badly worn valve body casting in the converter clutch regulator valve bore.
• Superior Shift Correction Package
  This shift correction kit corrects with these common issues: Runaway high pressure, Erratic pressure rise, Converter lock-up shudder. Inconsistent shift feel, Shift solenoid filter blow-out, and Premature unit failure
  A complete pressure regulator valve train is supplied in the 4L80-E kit. This corrects Fail-safe, runaway high pressure that will crack the case if not corrected. The PR valve train supplied in this Shift Correction Package will stop runaway high pressure before it happens.

Core information: Shipping cost only covers one-way shipping. Return shipping cost for the transmission core is not included in this price. Return shipping cost will be an additional $300. Returning the core is optional.

5" spline output shaft. No O-Ring.
E-brake location: rear wheels. No hole in end of
yoke. Tag ID: 9HPP, 0AKP, 0TZP, 1TZP, 9MDP, 9AKP,
7MJP, 9TZP, 0HPP, 6MJP, 7MCP, 616MCP, 616CAP, 617MCP,
615MJP, 615MCP, 615CAP, 614MJP, 614MCP, 617MPP,
619AJP, 611HPP, 610HPP, 610MCP, 614CAP, 611MJP.
